| GB | 205N 5 57C04J | ALTERNATOR DETAIL |
| 01 | 5727 04 | 01 | ALTERNATR ROTOR |
 | |||
| 02 | 5720 67 | 01 | ALTERNAT STATOR |
| | |||
| 04 | 5761 60 | 01 | ALTERN REGULATR |
| | |||
| 05 | 5724 13 | 01 | ALTERNT BEARING |
| | |||
| 06 | 5733 69 | 01 | TERMIN PART SET |
| | |||
| 08 | 5744 69 | 01 | ALTR RR BEARING |
| RP 5724 13 | 01 | ||
| | |||
| 09 | 5725 C8 | 01 | ALTERNT BEARING |
| | |||
| 22 | 5744 43 | 01 |
DIODE PLATE LEFT |
| | |||
| 23 | 5744 42 | 01 | RIGHT |
| | |||
| 25 | 5746 41 NFP |
01 | PULLEY FIX PART |
| | |||
| 32 | 5734 41 NFP |
01 | ALTERN ROD SET |
| | |||
| 35 | 5728 45 | 01 | ALT BRUSH SET |
| | |||
| 36 | 5730 06 | 01 | SPRING SET |
