| 01 |
1001 49 |
01 |
ENGINE OIL PUMP
|
 |
| 02 |
0165 18 |
01 |
CENTRING BUS
|
| |
| 03 |
0165 19 |
01 |
|
| |
| 04 |
0326 18 |
01 |
PLUG SEAL 20X26
|
| |
| 05 |
1005 20 |
01 |
PUMP BODY
|
| |
| 06 |
1005 21 |
01 |
|
| |
| 07 |
1011 09 |
06 |
WASHER-SCREW 7X1,00X50
|
| |
| 08 |
1015 06
NFP |
02 |
OIL PUMP PLUG DIA 12
|
| |
| 10 |
1022 04 |
01 |
OIL PUMP GASKET
|
| |
| 11 |
1022 05 |
01 |
|
| |
| 12 |
1022 06 |
01 |
SUCTION GASKET
|
| |
| 13 |
1023 19 |
01 |
PUMP SHAFT
|
| |
| 14 |
1023 23 |
01 |
PUMP CONTR PINN
|
| |
| 16 |
1023 24 |
01 |
PINION ASSEMBLY
|
| |
| 17 |
1027 03 |
01 |
PISTON SPRING
|
| |
| 18 |
1027 04 |
01 |
DISCHARG PISTON
|
| |
| 19 |
1027 05 |
01 |
OIL PUMP PLUG
|
| |
| 20 |
1027 06 |
01 |
VALVE BALL DIA 12,70
|
| |
| 21 |
1039 32 |
01 |
OIL SUCTION
|
| |
| 22 |
1046 23 |
01 |
OIL PP STRAINER
|
| |
| 23 |
1046 24 |
01 |
LOCKING PLATE
|
| |
| 24 |
1024 05 |
01 |
WASHER
|
| |
| 9A |
6921 32 |
01 |
CAPSCREW 7X100-65
|
| |
| 9B |
6922 30 |
01 |
SELF-TAP SCREWS 7X100-48
|
| |
| 9C |
6932 05 |
01 |
HEXAGONAL NUT 7X100-5
|
| |
| 9D |
6962 70 |
01 |
FLEXIBLE WASHER 7X18-1,4
|
| |
| 9E |
6979 59 |
01 |
STOP-RING 12X9,45-0,8
|
|
